Brand:HT Italia
Description:GEO416 is a innovative earth ground resistance tester designed to performing Earth Resistance measurements with 3-pole standards method typically in industrial electrical installations environments which consists of single probes and more or less wide earth networks. This meter can perform also 2-pole measure (where auxiliary metal parts are available) extremely important in civil environments where 3-pole method application is not possible for logistical reasons. The earth ground resistance tester GEO416 performs tests with a high measurement range (up to 50kOhm) with a test current at high frequency in order to consider and eliminate noise voltages disturb on installation. Earth Resistivity test measure with 4-wire method it’s also very useful on preliminary calculation of earth installation dimension. A contextual help selectable by user it’s available on meter for each functions. The model can save each test result inside memory and can transfer saved dates to PC through optical / USB interface with dedicated Windows software.
Origin:Other country Italy
Model:GEO416
Packaging Details:carton boxes
Product detail:
- 3-pole Earth Resistance
- 2-pole Earth Resistance
- 4-pole Earth Resistivity
- High measurement range (50kOhm)
- Noise voltage measure
- Automatic calibration of test cables resistance
- Memory for saving tests
- Backlight
- Optical /USB PC interface
Codmetel : HV000416
- KITTERRNE : Set 4 cables + 4
meta l probes - COC4-UK : Set of 4 alligator clips
- BORSA2000N : Carrying bag for accessories
- ISO9000 calibration certificate
- User manual
- TOPVIEW2006 : Windows software + optical/USB cable C2006
- SP-0400 : Set of straps for use of meter on neck
- 1066-IECN : Connector for banana cables, black colour
- 1066-IECR : Connector for banana cables, red colour
CE MARK
IEC/EN61187
IEC/EN61557-1
IEC/EN61557-5
LVD 2006/95/CE Directive
VDE 0100
