PE, PVC Plastic pipe printer

FOB:perCarton/Cartons7600--10000RMB

Product detail:YYJ-1


 Applications：

Meter printer is the necessary equipment for production in wire and cable industry. The type of YYJ-1 meter printer with accurate meter and reliable performance produced by our company is the passive hot-press printing. The script printed on the external diamter of cable uses the method of hot-press printing to press the coating on the ribbon to the outer diameter of cable. The meter can print the out-of-factory name, trademark, model, etc,which is better than the ink printing mode, and is the updated product of ink printing type meter printer.

Specifications:

• Accurate Meter : the speed-ration of meter wheel and printing wheel is 1:1, which can ensure meter accurancy is within ±0.3%;
• Hot-press printing ribbon printing, clear script, good adhesion, not apt to erase and superior to the ink printing method;
• Meter figures of printing alphabet blocks adopt electric heating and temperature control regulation system is equipped for convenient adjustment, high precision of temperature control and stable printing quality;
• Easy operation and use, it can replac ink printer.

Main Technical Parameters
Rated voltage	380V
Rated Frequency	50Hz
Application Cable Diameter	φ8-100mm
Meter Accuracy	±0.3%
Heating Power	0.4KW
Temperature Control Accuracy	±0.5℃
Vortex Pump Power	1.1KW
Machine noise	≤85dB(A)
Dimension	900×540×1550mm

YYJ-2

Applications：

YYJ-2 of printer meters are based on imported sample machine principle design, it adopts hot-press printing way on the ribbon coating imprint in the plastic pipe, profile or the cable outer diameter, which is better than that of the printing ink, the meter accuracy, printing clear, reliable performance, and is an ideal measuring & printing equipment.


Specifications:

• High meter accuracy
• Clean script and good adhesion
• Easy operation and use

Main Technical Parameters
Applicable Tubing(Cable) Diameter	φ6-250mm
Meter Accuracy	±0.3%
Heating Power	0.3KW
Dimensions	900×520×1450mm
