Medical Hematology Analyzer

Technical Specifications:

Principle:

Electrical resistance for counting, hemiglobincyanide method and SFT method for hemoglobin

Parameters:

3-part differential of WBC; 20 parameters + 3 color histograms (WBC/RBC/PLT)

Sample Volume

Venous Mode: 9.6μL  Capillary Mode: 9.6μLPre-diluted: 20μL

Working Mode:

Counting passages detection + independent HGB measurement system; 24hours with auto standby

Operation Mode:

Windows operation system with ,keyboard &mouse input

Throughput:

35 samples/hour

Data Storage:

Up to 12,000 results inclusive of the histograms

QC mode:

L-J, ,X-B , SD, CV, QC histograms

Calibration Mode:

Relatively independent manual calibration and anto calibration in three detecting modes

Cross Contamination Ratio

WBC,RBC, HGB<0.5%, PLT<1%

Performance

Parameter Repeatability (CV %)

Linear Range

WBC≤2.5%

0.00-99.9×10⁸/L

RBC   ≤2.0%

0.00-9.99×10¹²/L

HGB ≤1.5%

0-300.0g/L

MCV≤0.4%

40-150fL

PL T      ≤5.0%(100-500)

0-999×10⁹/L

Display:

8.4”  LCD ,resolution:640*480

Reference value

Baby,kid,women,man,normal and customization

Interface:

2 × USB, 1 × parallel (for external printer), 1 × VGA (for external monitor), 2 × PS/2, 2 × RS-232(for network);

Printout

I Built-in thermal recorder, optional external printer, eight report formats

WorkingEnvironment

Temperature: 15°C~35°C; Humidity: 10%-90%;

Power Requirement

AC100-240V 50/60Hz
