PP Saddle Clamp Size

Product

 PP compression fittings saddle clamp

Material

Are constructed of PP. It is odorless, non-toxic and is tasteless, approved for use with drinking water

Product Description

PP compression fittings are available in a wide range of sizes to connect PE pressure piping applications or tubing sections

And they are typically used in irrigation system and water supply industries due to its high pressure strength and easy to install: just loosen the nut a few turns, insert the pipe, push the pipe in as far as it can go, tighten the nut and it’s done!

Available Colors

Black...

Brand Name

Berlyplast / OEM

Applicable Standard

ISO 9001-2008, Metric units

Features

Available in a full range of sizes from 25 mm to 250 mm

Fast and reliable connections,perfect sealing under all conditions

Internal and external corrosion resistance that are resistant to most

chemicals including salts, acids and alkali

Durable, cost effective, has high tensile and impact strength

Certain working pressure: 20ºC D20 - D63: PN 16 (threaded fittings: PN 10)  D75 - D110: PN 10

PP material is odor less, non-toxic and is tasteless,approved for use with drinking water

Application

Are available in a wide range of sizes to connect PE pressure piping applications or tubing sections and they are typically used in irrigation system and water

supply industries

Item Name

Size (mm)

Weight (g/pc)

QTY/Carton (pcs)

Saddle Clamp

25x1/2"

147

 200

25x3/4"

147

 200

32x3/4"

148

  200

32x1"

148

 200

---

---

 ---

250x1"

8566.7

 3

250x2"

8566.7

 3

250x3"

8566.7

 3

250x4"

8566.7

 3
