BKH SAE flanged industrial ball valve

Brand:aa

Product detail:

Bolev Hydraulics:

Bolev facilities, welcome your visit!



BKH SAE flanged industrial ball valve, 2 way ball valve series of SAE flange connections:

• SAE code 61, 62;
• up to 420bar;
• spilit flange connecitons.
• 3 pc structure;
• blow out proof structure;
• good interchangeabilities;

OEM and custom design is acceptable, but minimum order quantity will be requested.
Notice: throttle or half open/close would bring damage to ball seat, thus lead to leakage of ball valves.

Warrany: 13 months after date of on board.



Dimensions:





Part No.	PN	DN	LW	L	L1	B	H	h1	h2	h3	SW1	SW2	T	d1	d2	d3	O-ring under US norms
BKH-SAE-FS-210-13	210	13	13	151	47	35	49	18	38	10	09	30	6.8	24	25.5	30.2	18.6×3.5
BKH-SAE-FS-420-13	420	13	13	151	47	35	49	18	38	10	09	30	7.9	24	25.5	31.8	18.6×3.5
BKH-SAE-FS-210-20	210	20	19	162	60	48	70	25	55	11	12	41	6.8	31.7	31.9	38.1	25×3.5
BKH-SAE-FS-420-20	420	20	19	174	60	48	70	25	55	11	12	41	8.9	32	31.9	41.3	25×3.5
BKH-SAE-FS-210-25	210	25	24	178	65	57	79	28.5	64	11	12	50	8.1	38	39.8	44.4	32.9×3.5
BKH-SAE-FS-420-25	420	25	22	198	65	57	79	28.5	64	11	12	50	9.6	38	39.8	47.6	32.9×3.5
BKH-SAE-FS-210-32	210	32	30	191	84	75	101	37.5	84	12	14	60	8.1	43	44.6	50.8	37.7×3.5
BKH-SAE-FS-420-32	420	32	27	223	84	75	101	37.5	84	12	14	60	10.4	44	44.6	54	37.7×3.5
BKH-SAE-FS-210-40	210	40	36	231	91	85	112	42.5	95	12	14	70	8.1	50	54.1	60.3	47.2×3.5
BKH-SAE-FS-420-40	420	40	32	281	91	85	112	42.5	95	12	14	70	12.7	51	54.1	63.5	47.2×3.5
BKH-SAE-FS-210-50	210	50	48	232	100	104	131	62	112.5	12	14	90	9.6	62	63.6	71.4	56.7×3.5
BKH-SAE-FS-420-50	420	50	45	316	100	104	131	62	112.5	12	14	90	12.7	67	63.6	79.4	56.7×3.5
