Brand:aa
Product detail:
Series | SY3000 | SY5000 | SY7000 | ||||
Fuild | Air | ||||||
Internal pilot Operating pressure | 2 position single | 0.15~0.7MPa | |||||
2 position double | 0.1~0.7MPa | ||||||
3 position | 0.2~0.7MPa | ||||||
Ambient and fluid temperature | -10~50 (no freezing) | ||||||
Max operating frequency | 2 position single.double | 10HZ | 5HZ | 5HZ | |||
3 position | 3HZ | 3HZ | 3HZ | ||||
Manual override(manualoperation | Non-locking push type | ||||||
Pilot exhaust method | Common exhaust type for main and pilot valve | ||||||
Lubrication | Not required | ||||||
Mounting orientation | Unrestricted | ||||||
IMpact/Vibration resistance | 150/30(m/s2) | ||||||
Encloseure | Dustproof | ||||||
