Product detail:
Application:
AUJS series self-priming pumps are high efficient jet pumps with excellent suction even when there are air bubbles. The pump consists a single impeller, centrifugal pump and a jet pipe with a nozzle. The pump body is made of stainless steel, diffuser is made of Techno-polymer(P.P.O), Brass, or stainless steel, that make the pumps more particularly suitable for water supplying in domestic installations, small-scale agriculture watering and where self-priming operation is demanded, especially for home drinking water supplying and garden irrigating.
Operating conditions:
Liquid temperature up to 60
Ambient temper up to 40
Total suction lift to 9m
Continuous duty
Construct:
Pump body: Stainless steel
Impeller: Brass
Mechanical seal: Stainless steel/Carbon-ceramic
Motor: Closed, externally ventilated
Insulation class: B and F
Protection class: IP44 or IP54
Shaft: 45# Steel / Stainless steel
Thermal protector (if required)
Technical data(220-240V/50HZ)
Model | output power | lnch | kg | packing qty 40'cont | |
HP | KW | ||||
AUJS-60 | 0.37 | 0.50 | 1"*1" | 10 | 800PCS |
AUJS-80 | 0.60 | 0.85 | 1"*1" | 11 | 800PCS |
AUJS-100 | 0.75 | 1 | 1"*1" | 12 | 800PCS |
