Brand:aa
Product detail:
Congratulations,You have found a profitable business opportunity when you view this page,and also you have got a fine supplier who can support you on this field.
Waste tire/plastic/rubber becoming more and more serious,Many governments of the countries are trying to deal with this thorny problem.
How to deal with this problem? We have found a way,please read on...
Traditional processing method is burning or landfill.But there is serious pollution to air and soil,it was not right way.
Pyrolysis,not only averts the serious pollution but also has profit.
The principle introduction of waste tire pyrolysis machinery
Pyrolysis is thermochemical decomposition of tyre and plastic polymer, since waste tyre and plastic are long chain polymers containing more than 50,000 carbon atoms. The process will require an initial fuel source of coal, wood or oil. Oil gas produced flows through several successive condensers where the gas is cooled and oil gas is condensed into oil.
Working process of Waste scrap tire pyrolysis recycling plant to fuel oil
1. Processing time | |||||
Model | Load tires into reactor (hour) | Preheating time (hour) | Oil gas output time (hour) | Reactor cooling time (hour) | Carbon black steel wire discharging (hour) |
DY-1-10 | 2 | 2 | 8-10 | 3-4 | 2 |
2.Main parts of Waste scrap tire pyrolysis recycling plant to furnace oil | ||
Auto- Feeder |
1.60 tons hydraulic pressure. 2.Suitable to all kinds of materials. 3.Take steel out of the reator. 4.Save time, save labour, save energy. | |
Reactor |
1. Q245R boiler plate. Thickness: 16mm 2. Auto welding with weld seam 21mm to keep weld uniform and strong. 3. Safety. 100% X-ray flaw detection, inspecting weld defects. | |
Buffer Chamber
|
1. Reduce speed of oil gas, keep whole system running safely. 2. Purify oil gas. 3. Increase oil output rate. | |
Oil Water Separater |
1. Safety device, prevent gas reflux. 2. Separate heave oil and water.
| |
Condenser |
1.Three grade cooling device with The first step of cooling . 2.Totall cooling area 74 square meters to guarantee oil output rate. 3.Easy to install , easy for clearance. | |
Negative Device |
1. Running safely with Negative divece. 2. Working with auto feeder, no gas leakage, no pollution.
| |
Water Sealing |
Prevent gas reflux, keep safe running.
| |
Dedusting System
|
1.Reach the international purification standard. 2.Keep environmental friendly with SGSreport. | |
Unique devices specially used to test the steel plate of reactor
Reactor is the core part of the whole production line, therefore, we can say reactor's life decides the life of the system.
We pay much more attentioin to the reactor part production. For every batch of steel plate, we will use such special devices to test the quality of the steel plate to guarantee the reactor's service life. The life of our reactor is more than 8 years.
Delivery of waste tire pyrolysis plant to furnace oil
Total:Two containers,one 40ft FR and one 40ft HQ
Customer Preparation for Waste Scrap Tire Pyrolysis Recycling Plant To Furnace Oil
Advantage of Doing Company
1.Our belief :Doing is better than thousands of ideas.Our success comes from do it immediately.
2.Rich experience:equipment had exported to more than 18 countries.
3.With ISO9001:2008,CE Certificate.
4.Strict requirements for quality:
IQC:Incoming quality control,main raw material;
PQC:Process quality control,All the reactor is inspection by X-ray.
5.Running machine available for customer visit.
6.Factory area : 20000 square meter.
7.Production capacity:20 sets/month.
Xinxiang Doing Renewable Energy Equipment Co., Ltd specializes in manufacturing waste tires pyrolysis/recycling equipment. We have mature technology and professional sales team. And we have exported more than 50 sets of equipments to many countries and areas in 2011, such as Turkey, Albania, Macedonia, Iran, Ecuador, Poland, India, Malaysia, Bangladesh and so on.
After-Sales of Waste Scrap Tire Pyrolysis Recycling Plant To Furnace Oil
1. Delivery time- It will be 10-15 days after we receive the deposit.
2. Warranty- The warranty period for reactor and other parts except spare parts is 1 year.
The problem caused by wrong operation of workers shall not be responsible by our company.
3. Installation and Training-Our company will send one technician for each set of machine for guiding your installation,
testing the machine and training your workers.
During the installation period, buyer should pays $50.00 pry day to our technician;
And buyer should take charge of technician round trip air tickets and accommodation during
installation.
My customers and me
I am glad to be your consulstant for our waste recycling to oil production line.
Your enquiry is always welcome.
My mobile: +86-15090428245 SKYPE:JennyDoing
