Product detail:
panel solar
Product Details:
Monocrystalline Silicon Solar Panel, with TUV certified junction box with water proof
Max.power | 190W |
Size(mm) | 1580*808*35 |
Cell type | 125*125/6*12pcs |
Net weight(kg) | 14.5kg |
Vmp(V) | 36.8V |
Imp(A) | 5.16A |
Voc(V) | 45V |
Isc(A) | 5.58A |
Main Characteristics
1. High efficiency & high stability
2. Monocrystalline or Polycrystalline solar cells, range from 5Wp to 300Wp
3. Unique frame design to reinforce sealing and there are drainage holes on the border components, eliminate the framework of deformation caused by rain or snow accumulated in the framework
4. Strong aluminum frames to strengthen the load hold and to stand against high wind
Special mounting holes on the frames suitable for long term mounting
5. High transparency low iron tempered glass with enhanced stiffness and impact resistance property
6. Advanced EVA encapsulation system with multi-layer back sheets to better product modules
7. Output tolerance: ±5%, cell efficiency above 16%
8. Approvals: CE, IEC61215/61730, ISO, TUV
9. Back: TPT
10. Encapsulant :EVA
11. Frame: Aluminum alloy
12. Preeminent aesthetic appearance and easy installation
