Brand:aa
Product detail:
chinese LPG generator
| Cogeneration biogas specifitions | |
| Cogeneration unit | |
| Type of cogeneration unit | CHP100GF |
| Nominal electrical power output (kW) | 104 |
| Nominal heating power output (kW) | 135 |
| Nominal voltage | 400/230 V |
| Frequency | 60 Hz |
| Nominal power factor | 0.8 |
| Operating power factor | 0,8 – 1,0 |
| Operating pressure of gas on the inlet gas train | 2-5 kPa |
| Temperature gradient of heating system | 90/70 C |
| Water flow of secondary circuit | 1,73 l/s |
| Weight of cogeneration unit | 2450 kg |
| Dimensions (length x with x height) | 3600*1180*1760 |
| Exhaust temperature behind exhaust boiler | 125-185 °C |
| The engine comply with | ISO16949 |
| Noise pressure level of unit at distance 6m from canopy | 55+- 3 dB/A/ |
| Total recommended air exchange | 7200m3 /h |
| Self power load consumption | |
| Installed power load | 5,1 kW |
| Average operating power load (without emergency cooling) | 3,4 kW |
Engine specifitions
Engine type | HL6126NG-ZAL |
Norminal speed | 1500 MIN -1 |
Number of cylinder | 6 |
Bore * Stroke | 126*130 |
Displacement | 10 (l) |
Oil recommended (natural gas) | <0.22 m3/kw·h |
Lube oil filling quantity | min. 19 l, max. 22 l |
Max. lube oil consumption | 0,4-0,6 g/kWh |
Compression ratio | 11.5:1 |
Engine weight (dry) | 800 kg |
Generator specifitions
Synchronous alternator | Marthon MP-100-4 |
Nominal apparent power | 125 kVA |
Nominal active power | 100 kW |
Nominal voltage | 400/231 VAC, 50 Hz |
Harmonic distortion (no load/ linear balanced load | <1.8% / < 5% |
Dir. axis transient (X′d) | 11,0% |
Dir. axis subtransient (X“d) | 6,6% |
Quad. axis subtransient (X“q) | 7,2% |
Transient time constant (T′d) 100 ms | 100 ms |
Sub-transtime constant (T“d) | 10 ms |
Generator weight | 515 kg |
Bearing number | 1 |
FACTORY VIEW
TESTING SITE
UAE&GUANGZHOU FAIR
CONTAINER SHIPMENT
ASSEMBLY ON SITE
