Brand:aa
Product detail:
carbonization oven
Introduction:
Our carbonizing furnace is ideal equipment for wood briquettes to have anoxic distillation carbonization. Adopting reasonable structure, the carbonizing furnace needs small quantity of heat consumption only. And the most important is that our carbonizing furnace is equipped with Superheated Stream cooling system, thus can speed up the cooling process, improve the quality of charcoal and shorten the production cycling time to 24-48 hours with the features of easy operation, higher safety, high efficiency and energy saving. The final products charcoal briquette bars can be used for heating furnace, industrial boilers, biomass power plant, barbecue and so on.
characteristic:
Carbonization stove adopt superior purifying technology, and is made from special high temperature resistant material, and show the features of stable and wear well, freeing from oxidation and deformation, superior insulating property, easy operation, safety and reliable, no carbonization blind spot with double chimney, finished products ratio more than 95%, labour and time saving, and one person can operate several carbonization stove simultaneously.
Specification:
Dimensions, mm | Weight, MT | Volume, | Capacity, MT | Power kw | Temperature in the stove, °C |
2700×1700×2700 | 4.6 | 3 | 0.8-1 | 1.5 | 420-800 |
3600×1700×2700 | 5.4 | 5 | 1.2-1.5 | 1.5 | 420-800 |
3700×1800×2700 | 6.5 | 6 | 1.8-2 | 1.5 | 420-800 |
Advantage:
1. save the labour and energy
2. operation is easy, one person can operate 3-5 set carbonization stove.
3. continuous operation ,can working 24 hours continuously
4. it will need 12 hours for carbonzing and Wait for about 8-12hours to make sure the burning briquettes are completely cooled to normal, then open the furnace to check the quality the charcoal.(The principle is to touch the furnace to feel if it is in normal temperature) If the charcoal was not complete carbonized ,that shows t you remove the firebox early.
5. 24 hours can be carbonized one stove
