Brand:aa
Product detail:
outdoor full color p10mm led display screen,fixed installation and 62kg cabinet weight price 860usd/squre meter
Feature & Advantage
1. Waterproof and dustproof: IP68front, IP65back
2. Best viewing distance: 12-100m
3. White balance brightness: More than 8000CD/sqm adjustable
4. Horizontal viewing angle: 110degree
5. Working temperature: -20degree to +60degree
6. MTBF: More than 10, 000hours
7. Life span: More than 100, 000hours
8. Contrast ratio: 4000: 1
9. Average power consumption: 500W
Application and Market
1. Application
Wide applied in stadiums, advertisement, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
2. Market:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe
Specification:
Module:P10 | LED Type | DIP346 | |
Pixel Pitch | 10mm | Refresh frequency | 1,500Hz |
Module Size | 160x160mm | View Angle | 1100/750 |
Module resolution | 16x16pixel | Working Environment | Temp:-20°C~60°C, Humidity:10%~90% |
Dot density | 10,000pixel/sq. m | Working Voltage | AC:100V~120V AC:220~240V |
Pixel configuration | 1R1G1B | Lifetime | 100,000Hours |
The best view distance | 10-100M | Gray Scale | 14bit/color |
Cabinet dimension | 960mmx960mm(Optional) | Color Display | 1.07Billion |
Cabinet resolution | 96X96 | Brightness | ≥8000nit |
Cabinet weight | 58KG/sq. m | MITBF | 0.00001 |
Drive mode | Constant current,1/4 Scan | IP | IP65 |
Max Power Consumption | 600W/sq. m | Warranty | 2 year |
LED Parameter | R:d(625-630nm) R:IV(400-450mcd) | G:d(522.5-525nm) G:IV(1800-2200mcd) | B:d(467.5-470nm) B:IV(350-400mcd) |
Image adjustment | Brightness, contrast, tone, color range etc | ||
Brightness uniformity | Ratio of min pixel brightness /max pixel<0.9(When each color reaches its highest brightness) | ||
Effective control distance | Cat 5<100M / Multi-mode fiber:<500M / Single-mode fiber<20Km | ||
Color Temperature/contrast | Brightness and contrast of red, green and blue can be adjusted by software,100 scales are available, color temperature is adjustable | ||
Input signal | RF,S-VIDEO,RGB,RGBTV,YUT,YC,COMPISITION | ||
Control system | Sending card+Receiving card+Hub card+DVI Card+PCTV Non-liner card+Muti-funcational card(Optional)+Video processor(Optional)+ Fiber Transmitter(Optional) | ||
P10 outdoor full color module
Packing:(wooden case)
flight case
