Brand:aa
Product detail:
Ignition Electrode
Features
1) Many kinds of insulated ceramics available
2) It can satisfy constant's technical request
3) Lower medium spoilage
4) High resistance
5) Good lead-heat capability
6) Stiffness texture
7) High intensity
Parameter
| Properties \ Material | Unit | |
| Equivalent to DIN EN 60672 | C-786 | |
| Main Ingredients\Composition | SiO2 % | - |
| Al2O3 % | 94> | |
| MgO % | - | |
| Physical Properties | ||
| Colour | Pink / White | |
| Specific Gravity | 3.5 | |
| Water Absorption | % | 0 |
| Flexural Strength | KG/CM2 | 2500 |
| Compressive Strength | KG/CM2 | 12000 |
| Young's Modulus | KG/CM2 x 106 | 2.2 |
| Hardness | Moh's | 9 |
| Thermal Properties | ||
| Co-efficient of Thermal Expantion | 10-6/°K | 6.8 |
| (30-600 degree celsius) | ||
| Thermal Shock Resistance Down Shock T | °C | 350 |
| Thermal Conductivity | W / M°K | 14 - 24 |
| Max. Temp. Withstanding Capacity | °C | 1300 |
| Electrical Properties | ||
| Dielectric Strength (20C) | KV / mm | 15 |
| Dielectric Contant (20C : : 1MHz) | 9 | |
| Volume Resistivity (20C) | Ohm-cm | 1012 |
| Application | ||
| Ceramic gas ignition/ Pump Seal Faces / Flexible Band Heaters / Thread Guides | ||
Application:
All kinds of gas appliances, such as ovens, water heaters, boilers;
we are looking forward to your visit to our factory in Lianyungang, a booming port city to the north of Shanghai. you would be well received by us.
