Super Flexible Welding Cable 16mm 25mm 35mm 50mm 70mm2

Brand:aa

Product detail:

Super Flexible Welding Cable 16mm 25mm 35mm 50mm 70mm2
1.20 years experience
2.Good quality competitive price
3.Fast delivery



Details:



1. Welding cable Standard:



According to GB5013(Equal to IEC245),also can do by standard of ASTM,BS,DIN and AS/NZS or other standards.



2. Welding cable Construction:



Conductor:Copper or Tinned copper



Insulation: Rubber or PVC



Inner sheath:Rubber or Double insulation



3. Welding cable Description & Application



Model	Description	Main Application
YH	Natural rubber sheath for welding machine cable	Any welding applications.
YHF	Horoprene rubber or other synthetic rubber sheath welding machine cable



4. Welding cable Advantages



a. Extra flexible,Excellent electric and mechanical characteristics and wear-resisting.



b. Good resistance to oil,heat,flame,Supper abrasion resistant



c. Simple in structure,Convenient to use



 Any products specifications, appearance can meet your requirement. The product can continue working when it is in a very harsh environment. The most important thing, it is flexible,soft, oil-proof, fire/heat resistant and safe cable.



5. Welding cable Specifications, Size, Weight and Technical Data



Normal section (MM²)	Structure	Thickness of insulation (mm)	Approx. diameter (mm)		Conductor resistance at 20°C(Ω)	Approx. weight(kg/km)
	Root/diameter (mm)		Min.	Max.		YH	YHF
10	322/0.20	1.8	7.5	9.7	1.90	146	153
16	513/0.20	2.0	9.2	11.5	1.16	218	230
25	798/0.20	2.0	10.5	13.0	0.758	316	331
35	1121/0.20	2.0	11.5	14.5	0.536	426	439
50	1596/0.20	2.2	13.5	17.0	0.379	592	610
70	2214/0.20	2.4	15.0	19.5	0.268	790	817
95	2997/0.20	2.6	17.0	22.0	0.198	1066	1102
120	1702/0.30	2.8	19.0	24.0	0.161	1348	1392
150	2135/0.30	3.0	21.0	27.0	0.129	1678	1698
185	1443/0.30	3.2	22.0	29.0	0.106	1983	2020



About us:



Our factory manufactures and exports different kinds of Wires and Cables. We have many customers from all over the world,such as South America, Africa, Middle East, etc. And we do business with wholesales and distributors, export Single Wire,Surface Wire, Flat Cable, Flex Single Wire, Flex Round Cable, Telephone Cable, Speaker Cable, Coaxial Cable, Aluminum Conductor, etc. We are approved by ISO, CCC, CE, CB,VDE,SONCAP and so on.
