Brand:aa
Product detail:
1.diesel generator
2.famous engine
3.with high quality
4.soon deilvery time
Specifications
Engine: Famous Cummins, Perkins, Deutz, and Chinese reliable WEICHAI, SHANGCHAI ,SHANGNEI,WUXIDONGLI , NANTONG, LIJIA, QUANCHAI brands etc.
Alternator: Stamford, Leroy Somer, Marathon, and our Yihua brand brushless alternators TFW2(copy Leroy Somerand ), YHG (copy stamford) series, single phase ST ,three phase STC.
1) Insulation class: Class H
2) Voltage: 400V / 230V, 380V / 220V, 110V / 220V
3) Frequency: 50Hz, 60Hz
4) Protection class: IP 21/23
5) Power factor: 0.8
6) Voltage adjustment: ±1%
7) ATS for option
Warranty policy:
Guarantee for one year or 1500 hours (according to whichever reach first) from ex-factroy date. During the guarantee period, our YIHUA will provide the free easy-damaged spare part for problems caused by our quality of production or raw materials, except the damageable spare parts of diesel engine caused by customer's incorrect manmade operation. After expiration , our company provides cost spare parts maintenance for gen-set
Our generating set include the base fuel tank, the battery and 4 protection system for high water temperature, high oil temperature, low oil pressure, over speed and low battery conditions.
<
| Dg sets type | GFS-25KVA |
| Prime Output(KW) | 20 |
| Prime Output(KVA) | 25 |
| Rated Speed | 1500 rpm |
| Power Factor | 0.8(lagging) |
| Control system | DEEPSEA DSE702 |
| Silent Dimension(mm) | 1840*770*1015 |
| Silent Weight(kg) | 820 |
| Engine Type | FOTON (ISUZU) 4JB1 |
| Cylinder numbers | 4 |
| Induction system | Turbocharged |
| Type | water cooling ,in-line,4-stroke, direction injection |
| Capacity ( L ) | 2.771 |
| Bore × Stroke ( mm ) | 93*102 |
| Engine Maximum Power | 28 |
| Engine Continue Power | 24 |
| Engine Speed(r/min) | 1500 |
| Oil consumption (g/kW · h) | ≤215 |
| Governor | Electrical Governor |
| ALTERNATOR MODEL | YIHUA YHG-25KVA |
| Excitation | Brushless |
| Insulation Class | H |
| Protection Class | IP22 |
| Efficiency | 84.00% |
| Voltage Adjust Range | ≥±10% |
| Steady State Voltage Regulation | ≤±1% |
| Voltage Control | AVR |
