milling machine cnc 4040m(4000*4000mm)

Click for original picture
Fob Price: 3000.00 USD/
MOQ: 1
Payment Terms: delivery withindays since payment
Location: China
  Mr. Eric Yang    Contact Now 询价
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:aa

Product detail:



milling machine cnc









milling machine cnc 4040m(4000*4000mm)





1.best quality and the lowest price .

2.quick delivery and good service.

3.bulk discounts .

4.Seek agent.

5.believe and contact me to know more details  pls.







introtext:

  Suitable for Materials Engrave and cut on Acrylic sheet, ABS double color sheet, PVC foam sheet, wooden sheet, PCB Aluminum ,brass,steel



Wide range of application:

Such as seal, packing, scutcheon and pane making, decorating, art and craft,

architecture model, souvenir, badge, electric circuitry and carpentry field.



Suitable for Materials

Engrave and cut on Acrylic sheet, ABS double color sheet, PVC foam sheet,

wooden sheet, scagliola, PCB Aluminum sheet etc.



Features:



1. X Y Z use HIWIN square rails. Top precision , it makes machine working very stable.



2.Aluminium casting whole body wont transform for long use. Table move design make machine mor     e precise .
3. Imported all screw ensures stable movement and high accuracy
4. Advanced water-cooling brushless spindle, low noise, strong cutting strength

    and long-time mass processing.

5. Lower cost CNC machine for learning and beginners







Specifications:

Model

SM-4040m

X Y Z travel

400 x 400 x120 mm

Feeding height

120 mm

Structure

Aluminum casting structure.   table moving type

Movement parts

X   Y  Z ----ball screw

X  Y Z  --- HIWIN square rails

Motor

stepper motor

Driver

Stepper driver : brand -leadshine

Spindle power

1.5kw water cooling

Working Speed

0-4000mm/min

Control system

mach3

Command code

HPGL, G code

Working precision

0.05mm

Repeatability

0.01 mm

Power

AC220V±10% / 50~60Hz

Compatible Software

Type3/Artcam/UG/Pro-E/Mastercam/Ucancam V8 etc















NOTE: You can choose or quit different specification according to your work.







ABOUT US:



Jinan chentuo industry and trade Co.,Ltd is a Professional company for producting cnc router ,we are well known for our superior quality and service in the field of engraving and manufacturing of CNC Router and Laser Equipment.it includes CNC Router, CNC Laser engraving machine, CNC Laser cutting machine, CNC Plasma metal cutting machine and so on.



Our products are widely used in the following industry and field , such as woodworking, advertising, artmarking, model, electric, CAD CAM industry Model, clothing, packing printing, marking, laser sealing and so on. Suitable for Materials Engrave and cut on Acrylic sheet, ABS double color sheet, PVC foam sheet, wooden sheet, scagliola, PCB Aluminum sheet etc.



We have sold machines to a lot of coutries such as US, EU, Argentina, Morocco, Columbia, UK, Australia, Russia, spain, france, Esthonia, and so on.



Because the quality of our product is good,We have many distributors in China and abroad. Hope have a good cooperation with you.





.warranty period for cnc router machine: one year.





warranty period for spindle: half year.





Free replacement if there is a failure in warranty period .





If you have any question during you use our machine ,you can contact me online anytime.







 Samples:

















Application: Furniture processing industry, Decoration, Wooden art crafts ,Wooden door, cabinet making Suitable Materials: Wood , Plastic , Aluminum , acrylic, PVC, Composite panel , MDF, etc
