Stainless steel security access electronic turnstile barrier

Brand:aa

Product detail:

Electronic turnstile barrier



Electronic turnstile barrier specifications

Power	AC220C±10V,50HZ
Operating Temperature	-15°C-75°C
Relative Humidity	≤95%, No Condensation
Access Width	≤700mm
Passing Speed	30 persons/min(IC Card)
Motor	140W/24V
Motor Operation Speed	1600R/Min
Communication Distance	≤1200M
Input Connection	+12V Level Signal or Pulse Wide>100ms Pulse Signal, Current >100ms
Communication Connection	RS485 Communication Module Standard.
Material	SUS304,thickness is no less than 1.5mm
Running Life	5--8 Million(Continuous Opening and Closing Operation)
Protection Grade	IP54
Color	SSB(US32D)-Stainless Steel Brushed / Powder Coating(Optional), or other Color you like
Operation Place	Subway Station, Hoverport, Tourism Sports, Exhibition, Swimming Hall, Residence Area, Enterprise’s Entrance and Exit Attendance, Gateway Guard, Charge Management, Special Access Control











Electronic turnstile barrier functions and features:

 1. Single/double walkway---controlled in one direction or both
2. A valid lock action can allow one passage at one time
3. Normally open---the machine will unlock when a valid signal is received
4. It will lock automatically if passage through turnstile is not completed within pre-set time, the set time can be adjusted via parameter change
Emergency configuration: The tripod will drop automatically by power off or by hand to provide a clear walkway for escape in the event of an emergency
Interface: One standard port RS485
Control panel with count and LED digital function
Traffic-light: A Red Cross symbol will illuminate to indicate the unit is not available for pass, and a green arrow indicate the direction of allowable passing



Customer service:
1.All items have 24 month quality guarantee.
2. Custom design shape and logo,for large amount, custom logo available for free.
3. Supported by proffesional engineers.

4.Special discount  of our distributors or agents in their area.

5.Packing in standard export carton, suggest you pack it by wooden case to protect the products

6. CE, ROSH available.

Fast leading time:
For standard item
10-50 sets:5 working days
50-100 sets:7-10 working days
200-500 sets:10-15 working days
For special item, or need custom design package or logo, need 3-10 working days longer

Goldantell Turnstiles, factory price, high quality, welcome your inquiry!
