Brand:aa
Product detail:
Specification
1)white virgin Weather-resistant HDPE granules
2)Function:cable
3)Certification:SGS ISO9000
4)Environmental
Company Brief Introduction
1.With 15 years' manufacture & sales experience.We prefer long-term cooperation with you.
2.Main Product lines: black PE(LDPE,LLDPE,MDPE,HDPE) , PVC
white virgin Weather-resistant HDPE granules cable insulation grade
1.This product is used as sheath materials and insulation material for electric wires, cables and optical cables.
2. This first order is more than 50MT, the price can be discounted 10%.
3. Directly from factory, price in advantage. Welcome you as agent!
4. If the specifications can't meet you,pls contact me and give me your index.
It could be customized.
Specification of HDPE granule cable grade
QX211-White HDPE for cable insulation
| No. | Property | Unit | Test | Data |
| 1 | Melt Flow Index | g/10min | GB/T3682-2000 | ≤0.4 |
| 2 | Density | g/cm3 | GB/T1033.1-2008 | ≤0.955-0.978 |
| 3 | Tensile strength | Mpa | GB/T1040.3-2006 | ≥20.0 |
| 4 | Tensile yied strength | Mpa | GB/T1040.3-2006 | ≥16 |
| 5 | Elongation at break | % | GB/T1040.3-2006 | ≥650 |
| 6 | Brittle temperature at low temperature | °C | GB/T5470-2008 | ≤-76 |
| 7 | ESCR ,FO | H | GB/T2951.41-2008 | ≥500 |
| 8 | Ceka softening point | °C | GB/T1633-2000 | 110 |
| 9 | Tensile strength after thermal aging | Mpa | GB/T2951.12-2008 | ≥20.0 |
| 10 | Elongation after thermal aging | % | GB/T2951.12-2008 | ≥650 |
| 11 | Elongation at Low Temperature | % | GB/T2951.14-2008 | ≥175 |
| 12 | Dielectric strength | Mv/m | GB/T1408.1-2006 | ≥35 |
| 13 | Volume resistivity | Ω.m | GB/T1410-2006 | ≥1*1014 |
| 14 | Dielectric Constant ε | F/m | GB/T1409-2006 | 2.45 |
| 15 | Dielectric loss factor tgδ | -- | GB/T1409-2006 | ≤0.001 |
| 16 | Change rate of tensile strength after weather aging environment of 0--1008h | % | GB/T12527-2008 | ±25 |
| Change rate of elongation after weather aging environment of 0--1008h | % | GB/T12527-2008 | ±25 | |
| Change rate of tensile strength after weather aging environment of 504--1008h | % | GB/T12527-2008 | ±15 | |
| Change rate of elongation after weather aging environment of 504--1008h | % | GB/T12527-2008 | ±15 | |
| 17 | Thermostability stress crack | FO/h | GB/T9352-2008 | ≥96 |
Package: 25kg/bag craft bag with plastic bag inside or 500kg/bag
M.O.Q: 12MT/20'GP with wooden pallets
17MT/20'GP withour wooden pallets
24MT/40'HQ
Payment terms: 30%TT deposite and 70%TT against the copy of B/L. OR 100% L/C.
We are a mainly manufacturer in LDPE/LLDPE/MDPE/HDPE compounds in China for nearly 15 years. Our factory cordially cooperate with you, together development !
