Brand:aa
Product detail:
Seam Trackings, assistant automatic welding machine, can track welding seam of Gas cylinder. Below is introduction.
1. Functions
When the welding seam is long, not straight, or spiral, our machine can control welding torch move along welding seam direction strictly, thus saving cost, improving welding efficiency, ensuring machining precision, and achieving good internal quality and nice appearance.
2. Specification
Model | YXAWST-100C |
Rated Loading Capacity | 25kg |
Tacking Range | 100mm |
Maximum Tracking Speed | 350mm/min |
Accuracy | ±0.25mm |
Application Welding | GTAW, TIG, PLASMA |
Driving Motor | High-Quality DC Motor |
Driving Method | Motor Drive→Reducer→Ball Screw→Seam Tracker |
Input Power | AC100~240V Single-Phase,50/60HZ,2A |
Standard Configuration | Controller + X/Y Sliding Plate + Sensor + Sensor Adjust + Connecting Cables |
Accessories Option | Probe Sensor Cap/Tip , Remote Control Box |
Remark: We can also make seam tracker in special specification for user demands.
