Digital LCD Coating Thickness Gauge Car Painting Thickness Tester Paint Thickness tester DIY Instrum

Brand:aa

Product detail:



Technical Parameters



Model		F400		F1		F1/90°		F5	F10
working principle		Magnetic induction
Measuring range(µm)		0~400		0~1250				0~5000	0~10000
Resolution ratio(µm)		0.1		0.1				1	10
indication error	Calibration A	±(3%H+1)						±(3%H+5)	±(3%H+10)
	Calibration B	±((1-3)%H+0.7)			±((1-3)%H+1)			±((1-3)%H+5)	±((1-3)%H+10)
Test condition	Curvature radius(mm)	bulge	1		1.5		flat	5	10
	Dia.(mm)	Φ3			Φ7		Φ7	Φ20	Φ40
	Critical thickness(mm)	0.2			0.5		0.5	1	2







Model		N400		N1	N1/90°		CN02	N10
working principle		whirlpool
Measuring range(µm)		0~400		0~1250			10~200	0~10000
Resolution ratio(µm)		0.1		0.1			1	10
indication error	Calibration A	±(3%H+0.7)		±(3%H+1.5)			±(3%H+1)	±(3%H+25)
	Calibration B	±((1-3)%H+0.7)		±((1-3)%H+1.5)			-	±((1-3)%H+25)
Test condition	Curvature radius(mm)	bulge	1.5	3		flat	All flat	25
	MIN dia.(mm)	Φ4		Φ5		Φ5	Φ7	Φ50
	Critical thickness(mm)	0.3		0.3		0.3	unlimited	50µm Aluminum foil





Features of thickness tester

•         With different external probes, the gauge can be applied to measuring thickness of non-magnetic coating on magnetic metal substrate, as well as non-conductive coating on non-magnetic metal substrate.
• 10 types of probes (F400, F1, F1/90degree,F5,F10, N400,N1,N1/90degree , CN02,N10) are available for different application. F10 probe measures up to 10mm.
• Two measuring modes: single or continuous, changeable.
• Two calibration methods :Direct and A-B.can be applied to the gauge, And the system error of the probe can be corrected with the basic  probe calibration method.
• Five statistics:MEAN,MAX,MIN,NO.,S.DEV
• Measured values and user information are shown on a large, easy-to-read LCD. A display back light ensures easy reading of screen data in poorly-lit conditions.
• Measuring status indicator showing the measuring status.
• The gauges’ user-friendly measuring system permits automatic storage of up to 495 readings in one memory matrix for later statistical evaluation.
• Battery information indicates the rest capacity of the battery.
• Auto sleep and auto power off function to conserve battery life.
• Can be set limits: the measured value beyond the limit alarm automatically
• Compact aluminum case,suitable for use under poor working condition


  Configuration:

  Name	Quantity	Remarks
  Thickness tester	1 table	standard configuration
  F1  Probe	1 piece
  Calibration Foils	5 pieces
  Zero plate	1 piece
  The product packing	1
  Manual	1 volume
  Other type of probes		Options available

   The package of coating thickness tester
