1.2m LED Tube T8 Magnetic Ballast Compatible

Brand:aa

Product detail:

1.2m LED Tube T8 Magnetic Ballast Compatible



IES File&Dialux Solution Available





Features & Benefits:



• Direct Retrofit for conventional T8 fluorescent tubes with Inductive Ballast.

• Quick, simple and safe replacement without rewiring.



• 2835 SMD LEDs with high luminous efficiency.

• T8 size oval shape with G13 socket.

• Optimum light uniformity and high color homogeneity.

• Extremely robust with aluminum heat sink and polycarbonate cover.

• Power Factor: 0.95.

• Overpower, short and open circuit protected.

• NO noise, NO flicker, NO UV and IR.

• Mercury-free and RoHS compliant.

• Comply with CE, FCC and UL standards.



Physical Specifications

Length	600mm	1200mm	1500mm
Weight	212g	360g	441g
Housing	Aluminum Base+PC Cover
Lens	Milky/Clear
Tube Diameter	T8
Base Type	G13/R17d
Work Environment	Indoor use (applicable for dry environment)



Electrical Specifications

	600mm	1200mm		1500mm
LED Quantity	72LEDs	120LEDs	120LEDs	156LEDs	156LEDs
Power Consumption	10±1W	15±1W	18±1W	18±1W	22±1W
Output Current	250mA	360mA	430mA	430mA	530mA
Input Voltage	85 265VAC
Power Factor	>0.95
Light Source	2835 SMD LEDs, more than 21LM each
Operation Temperature	-20~40 °C



Optical Specifications

		600mm	1200mm		1500mm
Power Consumption		10W	15W	18W	18W	22W
Lumens	Clear	1100±10%lm	1600±10%lm	2000±10%lm	2000±10%lm	2500±10%lm
	Milky	850±10%lm	1400±10%lm	1800±10%lm	1800±10%lm	2200±10%lm
Luminous Efficiency	Clear	110lm/w	106lm/w	111lm/w	111lm/w	114lm/w
	Milky	85lm/w	93lm/w	100lm/w	100lm/w	100lm/w
Color Temperature	Warm White		Warm White:2800K-3200K
	Natural White		Natural White:4000K-4500K
	Cool White		Cool White:6000K-6500K
CRI	>80
Beam Angle	120 Degree



 Photo Show:
