LED Flexible 60leds/m 24v 5m led 5050 flexible white strip led 12v

Click for original picture
Fob Price: 2.00 USD/
MOQ: 50
Payment Terms: delivery withindays since payment
Location: China
  Ms. Mona Zeng    Contact Now 询价
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:aa

Product detail:

LED Flexible 60leds/m 24v 5m led 5050 flexible  white strip led lights 12v



Specification:



Item YH-RF30506012S-W
Power72W
Voltage12V/24V DC
Current6A
ColorR/Y/G/B/W/WW/RGB
Beam angle120 degree
IP gradeIP67
PCB colorWhite/Yellow
LED Qty60leds/m
LED chipEpistar
Warranty2 years
Certifications:CE&RoHS
Lifespan35,000 hours
Packing5m/reel





Features:


1.Power 5050 TOP SMD LED as lighting resources .
2.Available warm white ,pure white , cool white , red,blue , green, RGB
3.Input Voltage DC 12V or 24V .
4.Can be cut by 3 LED (DC 12v high output led strip ) and 6LED (DC 24v high output led strip ) and connect again by our accessories; With 3M adhersive tape back .
5.Can be chosen copper PCB or white PCB .
6.Anti-oxidation, anti-UV radiation and won‘t change color after long time use .
7.High flexibility ,high transparence, flame-proof and environmental friendliness .
8.Silicone material offers good heat or cold resistance and is not easily broken .
9.With silicone transparence waterproof connector can easily connect and totally waterproof .
10.Waterproof Material: Silicone hollow tube ,Silicone glue and Silicone transparent waterproof connector .
11.IP Waterproof level (IP65, IP66 and IP68 optional):
     IP65: cover with epoxy glue
     IP67: cover with silicon tube
     IP68: cover with silicon tube and epoxy glue
12.5m/reel pack in an anti-static PVC bag (vibration resistant), 3M adhesive tape on back for easy installation
13.Operating temperature: -20-+50degree

14.OEM/ODM, any label or brand
15.No danger of broken glass
16.Easy installation
17.Low Power Consumption, high intensity
18.Solid-State,High shock/vibration resistant











Other colors:







Our High Voltage DC110V/220V LED Strips:













Installation Diagram:



1.Install:Take out the package,make sure it comes with necessary accessories,which should include:fixing clips,middle plugs,end caps,head wires.fix the strips with clips onto where you need,put the wire into sockets to light the strips.



2.Cut: Please cut the strips only along the cutting mark on the PCB,don't cut at random.Block up the end with end caps,seal with enough glue to make sure it is still waterproof.



3.Connect: Plug the head wire into a strip to conduct the electricity,or plug a middle plug into the ends of two separate strips to connect them into a long strip,after well connected,seal all the plugs with enough glue.



How to connect LOW Voltage led strip?









Packing:









Certification:









Application:



1) Architectural decorative lighting
2) Archway, canopy and bridge edge lighting
3) Amusement park, theater and aircraft cabin mood lighting
4) Emergency hallway lighting
5) Auditorium walkway lighting
6) Stairway accent lighting
7) Concealed lighting
8) Backlighting for signage letters
9) Channel letter lighting
10) Emergency exit path lighting
11) Cove lighting









 Competitive Advantages:



1 Experienced technical staff

2 Advanced equipment

3 High quality

4 Experienced R&D department

5 OEM accepted

6 Strong production capability

7 Large scale production lines

8 Clients' special requirement accepted

9 Unique design



About us:



We are profession manufactory LED products in China. Products range includes LED strip, LED bulb light, LED tube light, LED down light, LED spot light, LED ceiling light and so on. The product has achieved CE, ROHS.Factory direct offering a competitive price with high quality .



1. Your inquiry related to our products or prices will be replied in 24 hours .

2.  Professional led manufacturer both on led component and application product .

3.  Professional support on technology and distribute direction .

4. Well-trained and experienced staffs to answer all your enquires in fluent English .
5. Distributorship are offered for your unique design and our current models .
6. Protection of your sales area,ideas of design and all your private information .
7. All the products must through 10 hours aging before delivery to ensure the quality .

8. 4 assembly lines, capacity of 500000pcs led lights in a month .

9. Unique appearance design and ideal recommended services are offered .

10. OEM&ODM are welcome , any your customized lightings we can help you to design and put into product .

11. On time delivery and prompt response to your enquiry .

12. Satisfied after-sales service,welcome all requires and we will reply promptly .



                                                 Welcome to visit our factory



Our Equipment and production process:





 Exhibition show:









Thank you for your time, our products range includes LED strip, LED bulb light, LED tube light, LED down light, LED spot light, LED ceiling light and so on. Looking forward to receiving your feedback.
