Brand:aa
Product detail:
| Main Parameter of W11 6X3000 3 ROLLER Rolling Machine | |||||
| Machine Structure | Mechanical | ||||
| Rolling Capability | Ós=245Mpa (Q235)/ T16×B3000×Φmin850MM | ||||
| Rolling Speed | 4M/MIN | ||||
| Upper Roller Diameter | Φ340MM | ||||
| Bottom Rollder Diameter | Φ260MM | ||||
| Centre-to-centre spacing Between Bottom Rollers | 430MM | ||||
| Main Motor | 15KW | ||||
| Dimension | 4700X1300X1300MM | ||||
| Main Character | |||||
| Using Electronical centralized control,easy in operation Using integrated chassis control system,convenient for equip and adjustment | |||||
| Main Components | |||||
| Main Reducer::Changzhou Guomao | |||||
| Main Motor:Nantong Hengli | |||||
| Gear:Wafangdian | |||||
| Low Pressure Electronic:Simens | |||||
| Standard Term | |||||
| JB/T8796-1998 | Precision of Rolling Machine | ||||
| JB/T8797-1998 | Basic Parameter of Middle and Small 3-Roller | ||||
| JB/T9971-1999 | Bending Machine,3-Roller Machine Noise Limit | ||||
| GB/T522601-1996 | General Technical Term and Condition of Merchanical Electronic | ||||
