AUYU Precise Panel Saw with Scoring Saw and Sliding table 3200mm APS3200/MJ3200C

Brand:aa

Product detail:

AUYU Precise Panel Saw with Scoring Saw and Sliding table 3200mm



Features

1. Movable table guide track is chrome plated round stick.

2. Plating chromium steel balls structure with high rating accuracy, exact and durable.
3. Made of high-strength extruded aluminum alloy, movable table is high in strength and won’t bend.
With oxidation treatment, movable surface is beautiful and hardwearing.

4.The inclination between the major saw blade and saw blade are visually displayed by electronic precision instrument.

5. 2200mm, 3200mm,3800mm length sliding table, 375mm width

6. European and Italy dust hood optional

7. 3kw, 4kw and 5.5kw motor optional







Main Technical Specification



MODEL	APS-2200/ MJ6122C	APS-3200/MJ6132C	APS-3800/MJ6138C
Size of sliding table	2200x320mm	3200x375mm	3800x375mm
Size of main body	1900mm	1900mm	2700mm
Max. Lengthways cutting	1250mm	1250mm	1250mm
Dia of cutter blade	Φ300-400mm	Φ300-400mm	Φ300-400mm
Cutting thickness (Φ300mm)	80mm	80mm	80mm
Dia of main spindle	30mm	30mm	30mm
Speed of main saw blade	4000/6000rpm	4000/6000rpm	4000/6000rpm
Main motor power	3.0kw	5.5kw	5.5kw
Speed of scoring saw blade	8000rpm	8000rpm	8000rpm
Dia of scoring spindle	20mm	20mm	20mm
Tilting saw blade	0-45°	0-45°	0-45°
Dia of scoring saw blade	Φ120mm	Φ120mm	Φ120mm
Scoring saw motor	0.75kW	0.75kW	0.75kW
Overall dimension	3050×3150×900mm	3500×3150×900mm	4100x3150x900mm
Weight (approx)	1030kg	1170kg	1275kg

















































Round Stick Rail



Sliding table 2200mm,3000mm,3200mm,3800mm for your choice









Workshop for Panel Saw







AUYU ALL IS FOR U!
