Brand:aa
Product detail:
mini cnc waterjet cutting machine for sale
Characteristic:
1.high accuracy ball bearing guide screw of taiwan,minimize the slit.
2.imported linear rail,self lubricating glide.
3.our routers have the features of recarving after stop and the power failure may be restored.
4.unique preservation way of the zero point.
5.use for long time and no distortion.
6.this type is suitable for advertisement.
Performance parameter:
number | Description | parameter |
1 | XYZ working area | 300*300*80mm |
2 | Table size | 420*560* |
3 | XYZ travel positioning accuracy | ±0.05mm |
4 | XYZ repositioning positioning accury | ±0.05mm |
5 | Table surface | Aluminium + PVC |
6 | frame | cast Aluminium |
7 | drive system X-Y axis | Ball screw |
8 | drive system Z axis | Ball screw |
9 | Spindle power | 1.5KW |
10 | Max velocity | 8m/min |
11 | Max working speed | 6m/min |
12 | Spindle speed | 0-24000rmp |
13 | work mode | Stepper |
14 | Working voltage | AC220V |
15 | Command language | G code |
16 | Interface | USB |
17 | Operating system | Ncstudio |
18 | Flash memory | 128 |
19 | X-Y resolution | less than 0.025mm |
20 | Software environment | Ucancam, Type3, Artcam |
21 | Running environment | Temperature:0-45°C |
22 | Paking size | 810*810*800mm |
23 | Net weight | 85kg |
24 | Gross weight | 110kg |
Beautiful Performance:
main parts:
the cnc router :
3030A:
3030B :
the sample:
our workshop:
The packaging:
inner with dampproof plastic film
outer with wooden case:
Warranty and After service:
1. Our warranty is 12 months counting from the date when the Machine arrives at the port of destination. We provide maintance free of charge during the period warranty(excluding damaged artificially), While user is kindly requested to send the damaged parts to us before we send back the alternative parts. After the guarantee of quality
period,we will charge for damaged parts.
2. It is inconvenient for our engineer to help clients to use the machine face to face,so provide the following technical supports methods:email, MSN/Skype, camera, video,
telephone and fax,you can contact with us at any time.
3.When some problems can’t be solved by the mentioned technical support methods,and require our engineer offer help face to face,we hope customer can help us to
deal with the visa and prepaid return ticket and arrange our engineer’s accommodation. Customers also can send their engineers to our factory, we will offer long-term technical training for free.
Welcome to visit our website:
www.ht-cnc.net
If you need more information or have interests about our products.Pls contact me at any time or send me the email. Thank you.
