Brand:aa
Product detail:
Laminator Parameter:
Specification | FY850 | FY1350 | FY1950 |
Max.Laminating Width | 800MM | 1350MM | 1900MM |
Max.Laminating Thickness | 30mm(general) 40mm(special) | ||
Max.Laminating Length | Unlimited | ||
Laminating Speed | 0-6mm/min | ||
Operate Method | Auto | Auto | Auto |
Roller diameter | 130mm | 130mm | 130mm |
Roller upgrade | pneumatic | pneumatic | pneumatic |
Fixed input power | 1500w | 2000w | 2500w |
Roller heating | Internal heat by infrared | Internal heat by infrared | Internal heat by infrared |
Temp range | 0--80C | 0--80C | 0--80C |
Improve quality
Infrared temperature control, temperature control is more precise.
The film will be stickier and have better scalability and no air bubbles after heating.
Improve success rate
The takeup part can be adjusted to improve the ductility of the coat without wrinkle.
Adaptive pressure device, and there is no need to frequently adjust the coating pressure.
Improve efficiency reduces labor costs
Automatically reveal the base coat to save labor.
Continuous laminating of the same thickness of the plates.
Complete 360m2/h by one or two people.
Long machine life low maintenance costs
Foreign silicone rubber roller, thermostable, good elasticity, anti-aging.
The seamless thickened rolling roller of steel pipe can be used for a long time without deformation.
Using an independent rubber band that can be replaced individually.
A multi-purpose machine
Can be used for hot and cold laminating of pictures and other materials.
Laminate the crystal and greatly reduce coating cost.
All the flat plate materials can be laminated
