PVC/UPVC/CPVC Pipe Production Line
Application
PVC/UPVC/CPVC Pipe Production Line mainly used for producing pvc drainage pipes, pvc water supply pipes, pvc conduit pipes and so on.
The whole PVC pipe production line include: Material charger, SJSZ series conical twin screw extruder, pipe mould, vacuum calibration tank, haul-off machine, cutter and stacker; pipe printer and PVC Pipe Belling machine for customers optional choice.
SRL-Z series PVC Powder heating cooling mixing unit, SWP series Plastic Crusher, SMF series Plastic Milling Machine/ Pulverizer are necessary auxiliary equipments.
Main Technical Parameters
Model | Pipe diameter | Extruder | Max. Capacity | Max. speed | Total Power | Total Length |
PVC-50 x2 | Φ16-50mm x 2 | SJSZ 51/105 | 150 kg/hr | 6 m/min | 60 kw | 20m |
PVC-63 | Φ16-63 mm | SJSZ 45/90 | 120 kg/hr | 10 m/min | 45 kw | 20m |
PVC-110 | Φ50-110 mm | SJSZ 51/105 | 150 kg/hr | 6 m/min | 60 kw | 24m |
PVC-160 | Φ75-160 mm | SJSZ 65/132 | 300 kg/hr | 5 m/min | 100 kw | 24m |
PVC-250 | Φ125-250 mm | SJSZ 80/156 | 400 kg/hr | 3.5 m/min | 120 kw | 28m |
PVC-315 | Φ160-315 mm | SJSZ 80/156 | 400 kg/hr | 3 m/min | 160 kw | 28m |
PVC-450 | Φ250-450 mm | SJSZ 92/188 | 700 kg/hr | 1.5 m/min | 200 kw | 36m |
PVC-630 | Φ315-630 mm | SJSZ 92/188 | 700 kg/hr | 0.9 m/min | 230 kw | 36m |
