Energy Saving Automatic Plastic Injection Machine/Injection Molding Machine

Brand:aa

Product detail:

Energy Saving Automatic Plastic Injection Machine/Injection Molding Machine

Brief Introduction:



Plastic Injection machine Adopting Europe technology,hydraulic unit adopts proportional pressure and flow control,the pressure and the speed can be adjusted,stable movement curve and gentle shock,the computer is imported from Industry family. The LCD displaying screen with high clarity has Chinese and English language to use. Close-loop PID temperature control with the advantage of high precision. The operating table of the Plastic injection machine have two safety, one is machine safety, another is electrical safety, that ensures the operators’s  safety.



Energy Saving Automatic Plastic Injection Machine/Injection Molding Machine

Technical Flow Chart:





Energy Saving Automatic Plastic Injection Machine/Injection Molding Machine

Technical Parameter:



Item	Unit	Data
Max. clamping force	KN	1300
Max. opening force	mm	400
Space between tie bars(V×H)	mm	420×420
Mould height(min-max)	mm	160-440
Max. daylight	mm	840
Ejector force	KN	31.4
Ejector stroke	mm	100
Ejector quantity		5
Screw diameter	mm	35	40	45
Screw L/D ratio	L/D	24	21	18.7
Theoretical shot volume	cm3	173	226	286
Plasticising weight(PS)	g	158	206	260
Injection pressure	Mpa	235	180	142
Theoretical injection rate(PS)	g	110	143	181
Plasticising capacity(PS)	g/s	13.8	19.7	27.1
Screw torque	N.m	740
Max. screw rotate speed	r/min	250
Injection stroke	mm	180
Carriage push force	KN	55.2
Pump motor power	KW	15
Pump pressure	Mpa	16
Heating power	KW	9.2
Heating zone		4
Size(L×W×H)	m	4.7×1.25×1.85
Net weight	t	4.3
International designation		1300-410











































































Energy Saving Automatic Plastic Injection Machine/Injection Molding Machine

Pictures Show:



Plastic Injection machine -- Moulds:





Plastic Injection machine -- Auxuliary Parts:

Plastic Injection machine -- Package For Delivery:



Plastic Injection machine -- Our Factory:



Plastic Injection machine -- Certifications:
