PET waste bottles washing machine plastic recycling machine

NO

ITEM

DESCRIPTION

1

Prewasher

Remove the solid impurity which are water insoluble, such as hand stone, sand, etc. It can also wash bottles' surface.

2

Bale Breaker

It is used in large capacity recycling line, and bottles are compressed in bale.

3

Belt Conveyer

Including the metal detector.

4

Label Remover

Label removing efficiency, more than 98%

5

Manual Select Platform

Made according to workers' height, supply a suitable plate for selecting the left labels or some other impurity.

6

Belt Conveyer

Conveying the bottles into crusher.

7

Crusher

With water, the materials of the blade adopt SKD-II or 9CrSi. It has a function of prewashing too.

8

Screw Feeder

Conveying the flakes into friction washer.

9

Friction Washer

Scrubbing material in high-speed with water.

10

SCrew Floating Washer

Remove few remand paper, sand, label from material based on different density.

11

Screw Feeder

Conveying the flakes into hot washer.

12

Hot Washer

High temperature stirring washing with caustic soda. Water can be heated by steam or electric.

13

Screw Feeder

Same as Item 8.

14

Friction Washer

Same as Item 9.

15

Screw Floating Washer

Same as Item 10.

16

Dewatering Machine

High speed centrifuge drying.

17

Drying System

Electric heating wind drying.

18

Label Wind Separator

The last left impurity will be separated from flakes by the blower fan.

19

 Silo

Store the final material.

20

Electrical Control Panel

Adopts Siemens and DELIXI as main component.
