SGS approved high quality conical twin screw extruder

Brand:aa

Product detail:

conical twin screw extruder



Composed of barrel screw,gear transmission system,measurable feeding,vacuum deaerating,heating,cooling and electro control components etc.



Mainly used in plasticizing,extruding and forming PVC pipe,plate,sheet,film,profile,and pelletizing and other plastic products.



Main technical parameters:

Item\Spec.	SJSZ-51/105	SJSZ-65/132	SJSZ-80/156	SJSZ-92/188
Screw diameter ( mm )	51/105	65/132	80/156	92/188
Screw quantity	2	2	2	2
Screw rotating direction	Turning outwards with different direction
Rotational speed of screw ( r/min )	1-30	1-34.7	1-36.9	1-32.9
Valid working length (mm)	1200	1440	1800	2500
Motor power ( kw )	22	37	55	90
Barrel heating power ( kw )	18	24	36	86.8
Capacity ( kg/h )	80-140	250-300	320-450	500-600
Machine central height ( mm )	1000	1000	1000	1200
Net weight ( kg )	3500	4000	5000	10000
Dimension ( L*W*H )( mm )	3620*1050*2157	4235*1520*2450	4750*1550*2460	6725*1550*2814





                                                               conical   twin  screw  extruder







                              Inside     structure   of    conical   twin    screw   extruder





               Screw  &  barrel





                                                     Operation        control       panel





                                                      Inside   of   electric   cabinet
