Brand:aa
Product detail:
Adult diaper machine
1- The machine is able to produce two specification (S & L) products by changing cutting tools and gear box.
2- It has the process mechanism of cotton pulp high speed muller system, drum forming, embossing, elastic waistline, frontal tape, side tape, tri-folding etc.
3- Tri-piece standing cuffs on the surface to prevent side leakage.
4- The volume of S.A.P controlled by stepless regulator.
5- Phase adjusting units are used in the key sections of the equipment so that the phase can be adjusted during production without stopping machine.
6- Application of the vacuum conveying system guarantees the stress, stability and fixity of the product.
7- According to customers demand, it is able to produce patient under pad by adding some units.
8- It can be equipped with PLC control system, touching screen according to customers demand.
Adult diaper machine Technical Parameter
Power supply | 380V 50HZ |
Installation capacity | 85KW |
Designed production speed | 150 pcs/min |
Stable production speed | 80-100 pcs/min |
Product dimension
| a). S (1000×750)mm b). L (800×650)mm (customized) |
Waster Percent | less than 2% (excluding caused by glue applicators failure) |
Machine dimension | 20.5×1.7×2.8m (L×W×H) |
Weight | 30Tons |
OUR MACHINE----ADULT DIAPER MACHINE / ADULT DIAPER MAKING MACHINE
