Product detail:
toilet paper machine
Contact Miss Bonnie skype: gflotus 24hours vip hotline: +86-13503851305
toilet paper machine brief introduction:
I.technical parameter:
1.output paper :toilet paper,tissue paper.
2. raw material: waste paper
3.capacity: 1ton per day
4. net paper width:900mm
5.output paper weight: 13-40g/m2
6. rail gauge:1300mm
7.working speed: 40-100m/min
8. drive way: Alternating current, speed control, section drive
II.toilet paper machine structure and characteristics:
1. cylinder section:Φ1000mm×1100mm stainless steel cylinder mould 1set, Φ260mm×1100mm couch roll 1set,coated by rubber,rubber shore hardness 38°C±2.
2.dryer section:Φ1250mm×1100mm cast iron alloy dyer can 1 set, Φ300mm×1100mm touch roll 1set,1group scraper knife. rubber shore hardness 90°C±2.Mechanical pressure device.
3.paper cutting section: 787mm slitting machine1set .
4.drive and control section: Alternating current , speed control , section drive
III.toilet paper machine list:
NO. | Item | qty(set) |
1 | 787mm toilet paper machine. | 1 |
2 | exhaust hood of dryer can | 1 |
3 | Φ500mm axial-flow ventilator | 1 |
4 | 1.5m3High consistency hydrapulper | 1 |
5 | 0.8m2 High frequency vibrating screen | 1 |
6 | Φ250mm pulp refiner | 1 |
7 | Φ500mm Thruster | 2 |
8 | Sand remover | 3 |
9 | Suction box | 1 |
10 | 25m3bleacher | 1 |
11 | 4 inch Pulp pump | 5 |
12 | Vertical mixer | 2 |
13 | 33roots vacuum pump | 1 |
14 | 787mm slitting machine | 1 |
15 | Electricity control cabinet (Siemens of China) | 1 |
16 | 0.5T boiler(burn coal) | 1 |
IV.toilet paper machine service:
1. technical consultation;
2. project evaluation;
3. detailed design of factory;
4. installing and testing the whole production line;
5. training engineers and workers;
6. supplying spare parts for long time
V.toilet paper machine related photos:
(1)toilet paper machine producing workshop:
(2) toilet paper machine photo:
(3)toilet paper making process flow:
(4)toilet paper machine delivery:
(5) toilet paper machine client from nigeria:
(6) toilet paper machine certification:
(7) contact card:
