DPFM 6080 OF PIPELINE CONSTRUCTION INDUSTRY USED END PIPE BEVELER, PIPE CUTTING MACHINE OF HIGH QUALITY
| Type | DPFM6080 |
| Product size(L*W*H) | 3200X2650X3100 |
| Weight (KG) | 3200 |
| Applicable range | 60"-80" |
| Max. applicable wall thickness | 36mm |
| Clamping type | Internal centering hydraulic expanding mechanism: accurate centering, powerful clamping, safe and reliable |
| Bevel shape | V shape,U shape,mixed shap,combined innner and outer bevel shape |
| Beveling accuracy | Dimension tolerance ±0.05mm, angle tolerance ±0.5", Ra1.6 |
| Beveling efficiency (including auxiliary time) | Less than 4 mins |
| Hydraulic motor | SAUER DANFOSS |
| Cutting speed | 105m/min |
| Cutting depth | 0.2mm-0.6mm |
| Cutter | SANDVIK/WALTER |
| Operation system | Expanding/release, fast forward/fast backward, working feed, speed adjustment of working feed |
| Working pressure | Operating pressure:10 to 12MPa; Cutting pressure:0-18MPa |
| Hydraulic power unit | Motor type/Diesel type |
