Brand:aa
Product detail:
Multifuncation laser engraving & cutting machine
Key point:
Please kindly tell us your engraving or cutting materails, and materials size
Than we can quikly check and recommend to you the right machine.
Spcifications
The model | DW-1260 |
Working area | 1200mm*600mm |
Laser power | 80W |
Laser type | Hermetic CO2 glass tube |
Control system | DSP industrial control system |
Working table | Aluminum platform |
Mirrors | 3x mirrors Φ20mm |
Lens | 1x len Φ20mm |
Positioning accuracy | 0.01mm |
Engraving speed | 1~30000mm/min |
Cooling way | Water cooling and production system |
Format supported | BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG, |
Compatible software | CorelDraw, Photoshop, AutoCAD |
Interface | USB |
Application computer system | Windows 2000/Windows XP/Windows7 |
Cutting thickness | 0-8mm(depends on different material) |
Packing | Export plywood case |
Machine dimension | L1250mm*W850mm*H820mm |
Net weight | 80Kg |
Gross weight | 115Kg |
Attachment | Exhaust pump and pipe,water pump and pipe CD(software) data line, power line |
Engraving samples shows:
Machine picture show:
