Metal Pressing YDK-200 Frame Uplifting Hydraulic Press Machine



1.Suitable for:

YDK-200 Frame Uplifting Hydraulic Press Machine is suitable for Embossing,extruding shaping,light stretching,shaping,laminating and edge cutting for metal or non metal parts.It can press such typical products as watchcase,watchband,glass frame and parts,image frame,tableware,tags,lock,motor parts and metal parts etc.



2.Main Feature:

1.Apply general steel plate welding frame,feature outstanding rigidity and high press strength

2.Pressure,travel and pressure-keeping are customized according to the pressing techinque

3.With such derivative machines as lower lifting,upper lifting,upper and lower compound lifting,and light stretching etc

4.After closing the mould,it features quick pressing and only costs several seconds to reach the rated pressure.

5.Apply lower oil tank,convenient for replacing and cleaning the oil tank

6.Photo-electric protection device is equipped.



3.Main technical specification:

DESCRIPTION

UNIT

YDK-200

Nominal Capacity

KN

2000

Work Pressure

MPA

22

Max. Stroke Of Workable

MM

160

Distance From Workable and Lower Surface of Upper Beam

MM

450

Working Table Size

MM

530(L) x 510(W)

Speed Of Workable Rising

MM/S

190

Size Of Machine

MM

1120(L) x 1200(W) x 1465(H)

Motor Power

KW

5.5



The special specifications can be custom made separately
