Brand:aa
Product detail:
WD series Belt Dryer Equipment for mineral power balls
1.Company Introduction:
Zhengzhou Huahong Machinery Equipment Co., Ltd is a manufacturer and exporter of mining machinery in China. Our main products are crusher, ball mill, dryer, briquette machine and so on. They are excellent quality and enjoy good reputation both in China and overseas. Welcome to visit and purchase from us!
Use :
the mesh belt dryer is a kind of drying equipment for batch ,it is mainly for drying of plate ,strip and granular materials withbetter ventilation,the conveyor directly transports finished balls to the pallet conveyor ,and the scraping plate on the upper end of the pallet conveyor arranges these balls evenly on the dryer ,improving ventilation property of the balls ,achieving drying effect ,ensuring continuous pproduction of all equipment .
Main principle :
the principle is as follows :laid evenly on the mesh belt ,driven by the transmission device ,the materials move back and forth in the dryer ,where hot wind passes through the materials and the water vapor is diacharged from the weep hole .
Technical datas:
Model | WD6 | WD8 | WD10 | WD12 | WD16 | WD20 | WD24 | WD30 | |
width of Net belt(mm) | 600 | 800 | 1000 | 1200 | 1600 | 2000 | 2400 | 3000 | |
Length of drying section(m) | 6-12 | 6-12 | 6-16 | 8-16 | 8-22 | 10-26 | 12-30 | 12-40 | |
Length of feeding section(m) | 1 | 1 | 1 | 1 | 1 | 1.5 | 1.5 | 2 | |
Length of transmitting section(m) | 1 | 1 | 1 | 1 | 1 | 1.5 | 1.5 | 2 | |
Drying area(m2) | 3.6-36 | 4.8-48 | 6-80 | 7.2-96 | 12.8-105.6 | 20-260 | 28.8-360 | 36-600 | |
Unit mumber | 1-5 | ||||||||
Interlamellar spacing (mm) | 400-600 | ||||||||
Carrying capacity | 90-200 Kg/m2 | ||||||||
Operation temperature (°C) | carbon steel≤400 C°,stainless steel≤600 C° | ||||||||
Drying strength((kgH2O/h) | 5-20kg H2O/m2.h | ||||||||
heat source | hot wind,electricity,steam | ||||||||
Running speed | 0.06-1m/min | ||||||||
Transmission powder(kw) | 1.1-2.2 | 1.1-2.2 | 1.1-2.2 | 1.1-3 | 1.5-3 | 1.5-4 | 3-7.5 | 5-11 | |
Matching equipment | conveying equipment,air heating furnace,dust removing equipment,draught fan etc. | ||||||||
