Product Detail

Brand:aa

Product detail:

GYC-60B New Wire Cutting Machine

GYC-60B New Wire Cutting Machine is improved on the basis of the GYC-60A wire cutting machine, It is specially used to cut various foam concrete blocks. Easy operation, high efficiency.

New wire cutting machine main performances:

  1. Six shafts equipped with bearings, reduce the friction, and increase the rope wire lifetime.
  2. Both horizontal and vertical cutting are cutting both way, keep the blocks more stable, and get good shape blocks.
  3. Lifting speed could be also adjusted under the chain drive and lifting motor, more stable.
  4. Two cutting motors equipped on the cutting frame, save space, and make the structure more impact.
  5. Steel doors instead of the guard grids, more easy for daily maintenance.
  6. Add cover on the top of the cutting machine, make the cutter elegant appearance.
  7. Improved the control panel too, it is available for 380V/50HZ~460V/50HZ.
  8. The block size between 100-200-300-400-500-600-700-800-900-1000-1100-1200mm could be adjusted willfully.

Technical Data:

Item
