Brand:aa
Product detail:
Brief | |||
With front loader and back hoe, the AOYE 454/554 series tractor can do various kinds of job engineering with characteristics as following: | |||
1. With the fluid driving on whole structure, it has characteristics as compact structure and agile operation, which leads it work freely in incommodious field where large machine can not achieve. | |||
2. The working implements are connected with tractor in quick linkage type, and the hydraulic pipes are connected by quick coupling, which are easy for assembly. | |||
3 The tractor hydraulic system affords power to front loader, back hoe and tractor lift equipments. Hydraulic oil tank is designed according to the international standard, which is easy for maintenance. | |||
The specifications for the front loader | Model | LD400 | LD600 |
Matched tractor | 404/454 | 504/554/604 | |
Rated capacity of bucket (m3) | 0.3 | 0.46 | |
Rated loading capacitykg | 360 | 600 | |
Max. unloading heightmm | 2000 | 2200 | |
Unloading angleo | 42o | 42o | |
Max. unloading spacemm | 600 | 930 | |
Bucket lifting times | 7 | 7 | |
Max. shoveling depthmm | 100 | 110 | |
The specifications for the back hoe | Model | LW7 |
Matched tractor | 454/504/554/604 | |
Max. digging depthmm | 2150 | |
Max. flatting depthmm | 2000 | |
Max. digging heightmm | 3400 | |
Rated Volumem3 | 0.048 | |
Transportation heightmm | 1760 | |
Working pressureMPa | 16 | |
Max. digging radiusmm | 3360 | |
Bucket turning angleo | 160 o | |
Moving arm turning angleo | 140 o |
