Brand:aa
Product detail:
mine wheel loader
The TNN Development Limited is the oversea group of ZT machine.
http://www.taztjx.cn
http:// www.tnn.com.cn
widely used in the construction of coal mine and mineral.
Description | Specification |
rated load(kg) | 2000 |
operating weght(kg) | 3250 |
Max.dump height(MM) | 3500 |
Discharging Angle(°) | 45 |
Lifting time(s) | ≤4 |
Total cycle time(lifting, dumping, lowering)(s) | ≤12 |
steering angle(°) | 35 |
Min turning radius(MM) | 4800 |
Wheel base(MM) | 1970 |
Tread(MM) | 1370 |
Min.ground clearance(MM) | 230 |
Overall dimensions (l×w×h)mm(MM) | 4500×1750×2550 |
travel speed(km/h) |
|
Forward gear I | 0~6.5 |
II | 0~16 |
reverse gear I | 0~6.5 |
II | 0~16 |
Engine Model | 498BG |
Type | In line, water cooled, four stroke, dir.inject |
Rated power(kW) | 40 |
Rated speed(rpm) | 2200 |
