Brand:aa
Product detail:
A :Specifications of ZL 12F mini loader
1.0 Engine Details
(1) Model: xinchai498
(2) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 36.8KW
2.0 Transmission System
(1) Type: Fixed-spindle Power shift
(2) Shift gear control oil pressure: 1.2~1.5MPa
3.0 Bucket
(1) Bucket Capacity: 0.7 m3
(2) Bucket width: 1750mm
(3) Bucket type: Heavy-duty bolt on teeth
(4) Max. Breakout Force: 36.8KN
(5) Rated Load: 1500kg
(6) Operating Weight: 3300kg
4.0 Overall Dimensions
(1) Overall Length (Bucket on ground position): 5200mm
(2) Overall Height
(a) Ground to Cab Top: 2670mm
(b) Dumping Height: 2650mm
5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4500mm
(3) Driving System: Hydraulic converter
6.0 Brake System
(1) Service Brake: Four Wheel Hydraulic spread-shoed brake
(2) Parking Brake: Hand operated
7.0 Tyre (1) Model:12-16.5
B:different color model
C ATACHMENT:
ENGINE JOYSTICK
D:PACKING:
1 SET/20GP 3 SETS/40HQ
mini loader OPTIONAL:
1)PERKINS ENGINE, DEUTZ ENGINE AND DOMESTIC ENGINE AND MORE
2)WITH OR WITHOUT (JOYSTICK SYSTEM)
3)ENCLOSED CAB WITH OR WITHOUT AIR CONDITIONER OR HEATER
4)ALL KINDS OF TIRES ( SOLIC, NORMAL, CACUUM) AND DIFFERENT TYPE FOR CHOICE
5)VARIOUS OF ATTACHMENTS:
wheel loader
1.Using direct injection diesel engine as power, with easy startup and low oil consumption
2. Using special drive axle, with strong ability to overcome obstacle
3. Chassis uses hinged structure, with small turning radius and flexible turning, which applies to the operation in narrow space
4. This machine uses hydraulic operation, with simple structure, convenient operation, good performance and reliable quality
5. Widely applying to the construcction of agricultural engineering and small and medium building such as road, coal mine,
brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc.
welcome your inquiry!
