FCYJ -1 Underground Mining Loader from the big factory
1. Underground Mining Loader FCYJ - 1 adopts Ac 380 V three-phase asynchronous motor, rubber tire, front and rear axle drive at the same time.
2. Adopts the advanced way of adopts hydrostatic transmission, gear-box and hub reduction gear, which changes the old models’ layout form of oscillating axle.
3. And it has overcome the defects of oscillating axle’s high failure rate, maintenance troubles, hidden dangers, greatly reduced the investment of manpower and material resources.
4. The running system adopts hydrostatic transmission, gear-box and hub reduction gear. Synchronous winding down device of cable was used in the process of walking to make the tractor shovel is more flexible in the work.
5. Suitable for mining and roadway drivage slag, the construction of the road and work place, material transportation and so on. The Electric LHD HKCYJ – 1has the advantage of compact structure, flexible and convenient operation.
Technical Parameter
Heaped Bucket Capacity:1 m³ | Payload Capacity:2000kg |
Max. Traction:52 KN | Max. Shovel Force :45KN |
Running Speed:0—8km/h | Max. Climbing Ability :16° |
Max .Discharge Height:1085mm | Min. Turning Radius : 350mm |
Max. Rotation Angle :±36° | Min. Ground Clearance :195mm |
Nominal Power :45kw | Max. Bucket Height:3600mm |
Effective Cable Length :100m | Weight(include hydraulic oil):7T |
Dimensions :6250*1300*1950 |
|
