Product Detail

Brand:aa

Product detail:

RA-50 Roof Insulation Spray Machine

Model

RA-50 Roof Insulation Spray Machine

Standard configuration

Mainframe 1 set

Self-cleaning spray gun 1 set

Feeding pump 2 sets

Heating hose 15m

Feeding pump hose 2.5m

Gun hose 1.5m

Rings and Tools 1 set

Technical Data

The ratio of raw material 1:1 or 2:1

The viscosity range of raw material 200-1000CPS (Under the operate temperature)

Max working pressure 20Mpa

Max fluid temperature 80ºC

Max output 9kg/min

Whole power 12000W

Voltage 2-ph 220V 50Hz/3-ph 380V 50Hz

Clean mode Self-clean by air

Max heating hose length 90m

Pneumatic source 0.9Mpa 1m³/min

Body size (L×W×H) 800×700×1200mm

Net weight 140kg



Mainframe

Feeding Pump

Spray Gun

Working
