Top design mobile double girder gantry crane

Brand:aa

Product detail:

  Top design mobile double girder gantry crane



Brief Introduction



MG gantry double girder crane (box type girder)electric crane is suitable loading and unloading materials in open storagedepots, materials yards, railroad freight stations, and harbor wharf. May also match by many kinds of special-purpose fishing tackles carries on many kinds ofspecial works. The bridge consists from double lying welding structure box.



Electric equipment for the trolley applying soft conductive cable, largecarts supporting sliding contact line, cable reel-type is available. It buildwith a closed air conditioning house with linkage platform control, so it has the advantages of broad vision, flexible control, comfort work, and high efficiency.



Safety Announcement



Users should lock the crane in time, when the crane stops operating on operating spot.



There is no electric wire above the total switch of the crane. Strictly forbid to use in such dangerous operating as easily combustible, explosive, corrosive, overloading, dust, etc.



Total length of suspending outside is less than1/3 of the span and 90%of suspending limiting-position (Gn). In addition, the trolley cannot travel until the heavy objects moved inside the support. If the trolley must travel outside the support, its heavy objects (Gn) should reduce 10%-20%. If total length of suspending outside is more than 1/3 of the span, the heavy objects (Gn) should reduce step by step, In a word, the trolley cannot travel until the heavy objects are near the support, and the crab isn’t suitable for traveling outside the support. Wind pressure should be less than 150pa.



 Technical parameter



Lifting Capacity			T	16/3.2	20/5.0	32/8.0	50/10.0	75/20.0
Span			M	18-35	18-35	18-35	18-35	18-35
Max. Lifting Height	Main Hook		M	10  12	10  12	10  12	10  12	10  12
	Aux hook			10.6-12.6	10.6-12.6	10.7  12.7	11.1  13.1	11.1  13.1
Working System				A5
Speed	Hoisting	Main	m/min	15.3	15	13.2	5.9	6.25
		Aux		22	19	17	13.2	9.28
	Tolley Travelling			44.7	44.7	38.6	36	38.9
	Crane Travelling			30-35	34.5-32.9	52.53	45   38.6	38.5   32.6
Weight	Trolley		t	7.1	8.1	11.7	16.8	29.4
	Total Weight			92-142	105-148	92-142	111-156	189-245
Max. Wheel Load				275-369	341-435	275-369	392-483	314-361
