Product detail:
Main Parameter
| Model | HZS60 | ||||
| Productivity | 60 m³/h | ||||
| Twin Shaft Mixer | JS1000 | ||||
| Mixer Volume | 1 m³ | ||||
| Mixer Power | 18.5kw×2 | ||||
| Max. Aggregate Size(broken stone/pebble) | 80 mm | ||||
| Loading Type of Aggregate to the Mixer | Converying Belt | ||||
| Aggregate Storage Hopper | 9 m³ × 4 | ||||
| Aggregate Weighing | 4000 kg ±2% | ||||
| Fly Ash Weighing | 400 kg ±2% | ||||
| Cement Weighing | 600 kg ±1% | ||||
| Water Weighing | 300 kg ±1% | ||||
| Additive Weighing | 30 kg ±1% | ||||
| Control Mode | Full-automatic / Semi-automatic / manual | ||||
| Total Weight | 45000 kg (excluding optional parts) | ||||
| Site Size (L X W X H) (at work) | 25000 mm × 10000 mm × 19400 mm | ||||
| Cement Screw Conveyor | LSY219/ LSY273 | ||||
| Cement silo(optional) | Bolted tyep: 50T/100T/200T | ||||
------------------------------------------------------------------------------------------------------------------
1. JS1000 Twin Shaft Mixer
2. PLD1600-4 Batch Machine
3. Belt Conveyor
4. LSY Cement Screw Conveyor
5. Control System
----------------------------------------------------------------------------------------------------------------------
