Brand:aa
Product detail:
Our patent product-New Automatic wall rendering machine
PLC Automatic wall rendering machine,cement sand plaster machine,wall painting machine SAW800
Advantages:
1, The volume is small, the weight is light , easy to move (automatic walking, automatic positioning, automatic adjustment of the plaster thickness , automatically adjust the plaster joints ) , easy to operate .
2,The unique design of the dual- rail automatic lift , automatic positioning , the main rail design height of 1.96m , host design : wide 78cm x long 80cm . Breakthrough of the biggest challenges of the whitewashed wall machine manufacturers of domestic and market can not solve so far for different floors of a high degree of automatic movements , and an effective solution across the room the construction of fills .
3,The machine is designed to squeeze plaster , plaster thickness up to 0.2 - 3cm not fall off , further strengthened the bond strength of the mortar and the wall , dense degree more than the manual more than five times , an effective solution to the artificial plaster in mortar off and hollowing phenomenon .
4,Positioning mode , our company developed a complete positioning system , combined with laser positioning ; the positioning is simple , fast , high precision . Really reached the whitewashed wall of the precedent of automation at home and abroad , to effectively guarantee the accuracy of wall roughness and verticality.
5,The professional design of automatic retractable motor adjustment control verticality and the second rail positioning to achieve the plaster , the whereabouts of the mobile location at the same time , significant savings in time and solve this problem up outside the host .
6,The unique design of the plaster thickness and the second plaster joints automatic retractable motor adjustment , the adjustment range between 2mm - 50mm , free to run , to achieve a degree of automation .
7,Yin and yang, the angle forming device is specifically designed based on years of experience in construction company's technical staff .
8,This machine equipped with operating platform, very lightweight, weighing only 20Kg.The base is provided with a universal wheel, can be very handy operation.
The main technical performance indicators.
Single-phase motor | 0.65kw | Startup mode | Control button ( distribution box) |
Motor speed | 1440n/min | Reducer | Reduction ratio30 :1 |
Plastering speed | 3.5m/39s | Plaster width | 0.3m- 0.8m |
Plastering height | 0.5- 3.5m | Plaster efficiency | 2.56 m2/39s |
Plastering time | 39s | A plastered area | 2.5 m2/39s |
Secondary calender time | 39s | Secondary pressure light area | 2.5 m2/39s |
Flatness error | ≤3mm | Vertical error | ≤ 3mm |
Flatness, plaster thickness , | 24v 30w | Walking speed | 10m/ Minute |
Vertical adjustment motor | 24v 30w | Alignment guide motor | 550W |
Walking mot | 550w | Reducer | 30 :1 |
Lifting motor | 0.65kw | Reducer | 30 :1 |
Console shape size | 30cm*50cm*80cm | Console weight | 20kg |
The plaster drive motor | 650w | Reducer | 30 :1 |
The main rail height | 176cm | Positioning rail height | 176cm |
Locate mode: Uses the company independent research and development a set of complete localization system
Promotion way : Design a dual- rail automatic movements , the main rail work , Vice rail positioning.
Construction effects: flatness, perpendicularity ≤ 3mm joints without a trace , strong bond, without hollowing , ripple-free , density greater than five times the artificial
Efficiency: 8 m2 / hour
Host Dimensions:78cm × 80cm × 40cm
Positioning time : 5 seconds
Plaster method: squeeze plaster
Motion way: Walks automatically
Lifting speed : 3.5m/39 seconds .
Machine weight : 80Kg
A plastering width:80cm
The main rail height: 196cm
Console Dimensions : 30cm X 50cm X 80cm
Operating weight: 20kg
Taking "Sincerity makes trust, Quality wins market"as our business philosophy, Our
company always puts quality in the first place and meet our customers' needs by ensuring
high quality products and the most professional services, Therefore, our products have
been exported to almost the whole world and enjoyed a good reputation from our
customer for years.
For warranty parts and service:
**1 year warranty.
**Within warranty period, all exchanges due to defects are free (Buyer is responsible for shipping charges).
** Within warranty period, As to after-sales service, all the freight fare and accommodation will be paid by buyer.
We are the only local leading manufacturer on this machine, and will offer installation CD,brochure and technology support as after-sale service!
