Product detail:
mortar plaster machine
automatic wall rendering machine/automatic rendering machine for wall/plaster rendering machine,0086-15238020768
1.The volume is small, the weight is light , easy to move (automatic walking, automatic positioning, automatic adjustment of the plaster thickness , automatically adjust the plaster joints ) ,
easy to operate .
2.The unique design of the dual- rail automatic lift , automatic positioning , the main rail design height of 1.96m , host design : wide 78cm x long 80cm . Breakthrough of the biggest challenges of the whitewashed wall machine
manufacturers of domestic and market can not solve so far for different floors of a high degree of automatic movements , and an effective solution across the room the construction of fills .
3.The machine is designed to squeeze plaster , plaster thickness up to 0.2 - 3cm not fall off , further strengthened the bond strength of the mortar and the wall , dense degree more than the manual more than five times , an effective solution to the artificial plaster in
mortar off and hollowing phenomenon .
4.Positioning mode , our company developed a complete positioning system , combined with laser positioning ; the positioning is simple , fast , high precision . Really reached the whitewashed
wall of the precedent of automation at home and abroad , to effectively guarantee the accuracy of wall roughness and verticality.
5.The professional design of automatic retractable motor adjustment control verticality and the second rail positioning to achieve the plaster , the whereabouts of the mobile location at the same
time , significant savings in time and solve this problem up outside the host .
6.The unique design of the plaster thickness and the second plaster joints automatic retractable motor adjustment , the adjustment range between 2mm - 50mm , free to run , to achieve a degree of automation .
7.Yin and yang, the angle forming device is specifically designed based on years of experience in construction company's technical staff .
8.This machine equipped with operating platform, very lightweight, weighing only 20Kg.The base is provided with a universal wheel, can be very handy operation.
The main technical performance indicators.
Single-phase motor | 0.65kw | Startup mode | Control button ( distribution box) |
Motor speed | 1440n/min | Reducer | Reduction ratio30 :1 |
Plastering speed | 3.5m/39s | Plaster width | 0.3m- 0.8m |
Plastering height | 0.5- 4.5m | Plaster efficiency | 2.56 m2/39s |
Plastering time | 39s | A plastered area | 2.56m2/39s |
Secondary calender time | 39s | Secondary pressure light area | 2.56m2/39s |
Flatness error | ≤3mm | Vertical error | ≤ 3mm |
Flatness, plaster thickness , | 24v 30w | Walking speed | 10m/ Minute |
Vertical adjustment motor | 24v 30w | Alignment guide motor | 550W |
Walking mot | 550w | Reducer | 30 :1 |
Lifting motor | 0.65kw | Reducer | 30 :1 |
Console shape size | 30cm*50cm*80cm | Console weight | 20kg |
The plaster drive motor | 650w | Reducer | 30 :1 |
The main rail height | 176cm | Positioning rail height | 176cm |
