HZS50 mini cement plant for sale
1. Description of hzs50 concrete batching plant
The concrete mixing plant is consisted of a mixing console, material weighing system, material handling systems,
material storage system and control system and other ancillary facilities. Floor aggregate metering station
ggregate measurement, reducing the four intermediate links, and is the measurement of the vertical blanking,
saving the measurement time, thus greatly improving the production efficiency, the same types of circumstances,
the mixing efficiency is higher than batching plant production efficiency by one third.
2.Advantages of hzs50 concrete batching plant
1.advantages HZS series of concrete batching plant is automatic concrete production equipment,with of less
investment small floor area, easy installation and transportation, and suitable for electricity, water , airport ,
high way,bridge etc. Construction projects and commercial concrete production .
2.JS type of twinshaft mixer is adopted, with the advantages of good mixing quality and high production efficiency.
3.Computer system can be controlled by manual, semiautomatic, or automatic, with the functions of storing ratio
and automatically compensation gap.
4.Various forms of combination can be provided according to customers’s requirements.
3.Main technical parameters
Specification | HZS25 | HZS40 | HZS50 | HZS75 |
Capacity(m3/h) | 25 | 40 | 50 | 75 |
Mixer | JS500 | JS750 | JS1000 | JS1500 |
Discharge Height (m) | 3.8 | 3.8 | 3.8 | 3.8 |
Feeding Volume | 800L | 1200L | 1600L | 2400L |
Discharging Volume | 500L | 750L | 1000L | 1500L |
Aggregate Measuring Precision(%) | ±2 | ±2 | ±2 | ±2 |
Cement Measuring Precision(%) | ±1 | ±1 | ±1 | ±1 |
Fly Ash Measuring Precision(%) | ±1 | ±1 | ±1 | ±1 |
Water Measuring Precision(%) | ±1 | ±1 | ±1 | ±1 |
Additive Measuring Precision(%) | ±1 | ±1 | ±1 | ±1 |
the Capacity of Aggregate Silo(m3) | 3×4 | 3×4.5 | 3×6 | 3×8 |
Cement Silo | SNC50 | SNC100 | SNC100 | SNC100 |
Fly Ash Silo | SNC50 | SNC100 | SNC100 | SNC100 |
Total Power(kw) | 44 | 75 | 110 | 150 |
The photos of hzs50 concrete batching plant
the following are the components of hzs50 mini cement plant
JS1000mixer for hzs50
this is concrete batching machine for hzs50
this is cement silo SNC100 for hzs50
this is control system for hzs50
Our factory
packing and shipping
customer 's visiting
