Brand:aa
Product detail:
FP05B Small-sized cement foam machine
Features and areas of application:
- Small sized but complete performance
- Mixing, foaming and pumping in one machine
- Single-phase power supply
- Applies to small scale scientific research and home floor heating
Specifications:
| Model No: | Specs | |||
| FP02B | FP05B | FP10B | ||
| Delivery Pressure(MPa) | 1 | |||
| Output(m3/h) | 1.5~2 | 3~5 | 8~10 | |
| Max conveying distance(m) | horizontal | 300 | ||
| vertical | 40 | |||
| Power supply type | Single phase | Single phase | three-phase | |
| Total power | 2.3 | 4.5 | 7.7 | |
| Mixer tank capacity(L) | 180 | 200 | 350 | |
| Filling height(mm) | 1300 | 880 | 1000 | |
| Weight(kg) | 480 | 910 | 1000 | |
| Dimension(mm) | 1600*640*1300 | 2100*1340*1390 | 2390*1490*1440 | |
| Feeder size(mm) | 2990*760*830 | |||
