Brand:Sengong
Description:1) Fully automatic multi-function packaging forming machine;
2) Bag shape: gusset bag, pillow bag, stand-up bag, etc.;
3) Suitable for all kinds of herbs and small puffed food like chips, corn flakes;
4) 10 electric scale weighers, touch screen control;
5) High precision and high speed, large volume;
6) All-round process: filing, weighing, bag forming, sealing, cutting and counting etc.
7) International Approval : ISO9001:2008
8) Quality Approval : Certification of Compliance
9) Experience : 12 Years Manufacturing
Origin:China Fujian
Model:T68S
MOQ:1Sets
FOB:perSets15000--20000USD
Port:Xiamen
Payment Terms:T/T
Supply Ablility:300Sets
Supply Time:Year
Delivery Time:2016-11-07
Packaging Details:Standard export carton package
Product detail:
//Application: //
It is used to pack kinds of grains or granules and small particles like rice, seeds, herbs, nuts, chips, con flakes, and proportional weighing other irregular-shapped materials.
//Main Structures and Performance Features: //
1.The whole production line integrates with stamped automatic packaging machine, dedicated precise combined balance with 10 heads, supporting table-board, dedicated chain drive conveyor and final product conveyor.
2.Servo film conveying system, accurate position, excellent performance, beautiful package effect.
3.Impeccable automatic alarming protection function, reducing the wear and tear to the lowest.
4.The machine can automatically perform the whole process like weighing, feeding, filling and bag-forming, date printing etc.
5.With high precision and high speed, digital weighing sensor makes the precise measurement realized immediately.
6.The balance can adjust fine the open-and-close speed of the hopper way, avoiding breakage and sticking.
7.The conveyor can load large volume, and lift high.
//Technical data://
Machine type: Automatic Granule Packing Machine Series
Machine model: T68S
Machine name: Automatic Herbal Granules Packing Machine
Machine form: Lapel stamped automatic packaging machine
Bag forming shape: Pillow bag, stand-up bag, gusset bag etc.
Bag size: L: 100-325mm; W:100-220mm
Filling range: 15~2000g
Packing speed: 25-40 bags/min
Control method: Touch screen control
Air Supply: 0.4m3/min, 0.8MPa
Power supply: 380V, 50HZ, three phase four wire
Gross power: 5.6KW
Thermal fuse power: 1.3KW
Machine dimension : 4200*1800*3360mm(L*W*H)
Machine weight: 1500KGS
