Hot sale Full automatic terminal crimping machine 7831

Brand:aa

Product detail:

1,Specifications



Model No.	YT-7831
Gauge	AWG1007#18-#28
Capacity	3600pcs/h
Drive mode	2 drives
Function	Cut,strip,crimp twist,Tin(with single end)
Cutting length	35mm-9999mm
Cutting tolerance	±0.2mm+(L*0.002mm)
Stripping length	NO.1:0-8mm,NO.2:0-15mm
Mould of crimping	Horizontal&perpendicular
Crimping machine	1.8T mute crimping machine
Control	Professional Central Process Unit
Test ability	no wire;tie a knot;crimp with fault way;low pressure
Voltage	AC220V-50/60Hz 20A single phase
Air pressure	0.5Mpa(140NL/min)
Measurewment	920*750*1450 L*W*H mm
Weight	350kg
Selected unit	Wire feed,Wire collect,CFM
